| Range | 4-5" |
|---|---|
| Resolution | 0.0002" |
| Measurement Units | Imperial |
| Data Output | No |
| Manufactured Standard | DIN 863, part 4 |
This Bowers XT Analogue Bore Gauge set is an economical solution to accurate shop-floor bore measurement. The extended mechanical travel of these advanced two point gauges ensures that exchanging measuring anvils is now unnecessary. The application range of this set is 20-30mm and has a rugged construction and easy read scale, ensure both accuracy and ease of use. XT measuring heads and setting rings are supplied with UKAS certification.
Range - 4- 5"
Accuracy- 0.00025"
Depth - 4.53"
Setting Ring - 5.000"
| Specification | Details |
|---|---|
| Barcode (ISBN, UPC, GTIN, etc.) | 5056202900896 |
| Accuracy | 0.00025" |
| Data output | No |
| Digital analogue | Anologue |
| Manufactured standard | DIN 863, part 4 |
| Measurement range | 4-5" |
| Measurement units | Imperial |
| Mpn | XTA100I |
| Product series | XTA Series - Bore Gauges |
| Product sub type | 3 Point Standard Micrometer |
| Resolution | 0.0002" |
| Waterproof | No |
