These Dial Snap Gauges offer the following benefits:-
You can adjust the measuring range with an adjustment nut.
Range: 125 - 150 mm
Anvil retracting stroke: 2 mm
Repeatability: 2 µm µm
Parallelism: 5 µm
Measuring force: 12 - 18 N
Remarks: For indicator with 8 mm stem
Mass_ 950 g
Measuring face: Carbide-tipped, micro-lap finish (13.5x12 mm)
Inch-Metric: Metric
Delivered: Including hand guard adjustable workpiece stop
| Specification | Details |
|---|---|
| Barcode (ISBN, UPC, GTIN, etc.) | 5055396191318 |
