Mitutoyo 264-620-IP U-Wave Fit IP67 Transmitter And Connector for IP Calipers. Mitutoyo’s U-Wave Fit wireless data transmitter fits to the back of popular Mitutoyo hand-held measuring instruments. This new design allows for a snug fit behind the display resulting in a more ergonomic feel. U-Wave Fit is the same technology as the U-Wave T, just a smaller version.• The transmitter is designed to fit in the space behind the display, and the connecting cable hasbeen replaced by a rigid connector• Approx. 20 m transmission range (within visible range)• 2.4GHz wireless system for reliable and secure data transmission• Easy data export to Microsoft® Excel® or SPC software applications• Transmitter confirms data transfer by an LED signal and optional buzzer• An IP67 transmitter is available to ensure a coolant-proof gaging system• Low power consumption: 400.000 data transmissions with a single battery
Measuring Instruments: 100, 150, 200, 300 mm IP67 caliper/standard caliper
Remarks: IP67
Data reception indication:LED (green, red, orange)
Transmission output: 2,5 mW (4 dBm) or below
Mass_ 20 g
Wireless communication protocol: Proprietary (2,4 GHz by original specification based on IEEE 802.15.4)
Power supply: Battery CR2032 x 1 pcs.
Communication distance: Approx. 20 m (within visible range)
Communication speed kbps: 250
Communication frequency: 2,4 GHz band (2,405-2,475 GHz, 15 channels, 5 MHz interval)
Communication with measuring tool: Digimatic (6 digits), Digimatic 2 (8 digits) automatic identification
OS compatibility: Windows® 2000 Professional (≥SP4), Windows® XP Professional (≥SP2), Windows® XP Home Edition (≥SP2), Windows Vista®, Windows® 7 (32bit, 64bit), Windows® 8, 8. 1, 10 (32bit, 64bit)
Battery life: Approx. 400000 transmissions
Dimensions (WxDxH): 56 x 30.4 x 11.5 mm
Functions: Measurement data transmission (cancel command, error command) and U-WAVE-R scan
Mitutoyo History - Celebrating over 80 years in the Metrology industry! Mitutoyo started from humble beginnings in 1934 in Japan and are now recognised as a world leading manufacturer of measuring tools such as micrometers, calipers, and system instrument products such as co-ordinate measuring instruments, form measurement instruments and optical measuring instruments
| Specification | Details |
|---|---|
| Barcode (ISBN, UPC, GTIN, etc.) | 5056202816449 |
| Mpn | 264-620 |
| Product sub type | Data Management |
